Tascam DR-10CH opptaker for Shure lavalier

Tascam DR-10CH recorder til Shure lavalier

DR-10C-seriens opptakere kan kobles til lavalier-mikrofoner for å skape et kompakt opptakssystem. Enhetene har både inputs og outputs, så de kan brukes alene eller sammen med en trådløs sender. Når de brukes med en sender, fungerer de som en backup, som beskytter mot trådløse dropouts under opptak. Den lettvektige DR-10C kan brukes i timevis på bare ett AAA-batteri. Den opptar til microSD media. Opptaksegenskapene inkluderer auto-gain og et low-cut filter. Enhetens Dual-Recording-egenskap opptar et sikkerhetsspor på et lavere nivå i tilfelle forvrengning.

Recording media: microSD card (64 MB - 2 GB), microSDHC card (4-32 GB)

Recording and playback formats: Mono WAV files (BWF format), 48 kHz, 24 bit

Analogue input (microphone): DR-10CS (for Sennheiser): 3.5-mm mini TRS jack (with screw lock), DR-10CH (for Shure): Mini XLR 4-pin male

Maximum input level: -12 dBV

Minimum input level: -53 dBV

Mic input gain: 10 dB to 35 dB (according to MODEL SELECT setting)

Input impedance: 33 kOhm or higher

Analogue output (passed to the transmitter): DR-10CS (for Sennheiser): 3.5-mm mini TRS jack (with screw lock), DR-10CH (for Shure): Mini XLR 4-pin male

Analogue output (Headphones jack): 3.5-mm mini stereo jack (dual mono audio output)

Frequency response: 20 Hz - 22 kHz, +1/-3 dB

Distortion: 0.05 % (1 kHz sine wave, maximum input level)

S/N ratio: 88 dB or higher (PHONES level max., MIC GAIN set to LO)

Supported operating systems: Windows 7, Windows 8 (including 8.1), OS X Mavericks (10.9), OS X Mountain Lion (10.8)

Power supply: 1 AAA battery (alkaline, NiMH or lithium), USB bus power from a computer

Power consumption: 0.45 W (maximum)

Current consumption (USB bus power): 0.25 A (maximum)

Date and time data retention: Secondary lithium battery (built-in)

Dimensions (W x H x D): 52 x 56 x 25 mm (excluding protrusions)

Weight: 63 g (with battery), 51 g (without battery)

Permissible operating temperature range: 0-40 °C
