Tascam lydgrensesnitt US-2x2HR USB 2.0 24bit / 192kHz

Tascam US-2x2HR USB 2.0 Audio interface 24bit/192 kHz

US-2x2 er en 2-input/2-output USB lyd/MIDI-interface perfekt for nybegynnere. Den tilbyr seriøse opptaksegenskaper med 96 kHz/24-bit kvalitet med brukervennlighet i høysetet. Mic preamps er nøkkelen til sublim lydkvalitet og US-2x2 tilbyr Ultra-HDDA mic-preamps med 125 dBu EIN rating som betyr den har et meget lavt støynivå. På grunn av den brede dynamiske vidden kan interfacen både brukes sammen med dynamiske og kondensatormikrofoner. Dette gjør enheten optimal for opptak av vokal, piano og akustiske gitarer. US-2x2 kan brukes sammen med DAW-applikasjoner, den kan også brukes som en lyd-interface med iPads og andre populære iOS-enheter, ved bruk av en Apple Lightning-to-USB kamera-adapter (en ekstra AC-adapter er nødvendig når US-2x2 brukes sammen med iOS-enheter).

Advanced version of our popular US-2x2 with even better sound quality

Provides two audio inputs and two audio outputs as well as a MIDI interface to a Windows or Mac computer or iOS device

Audio resolution up to 192 kHz / 24 bit

USB Audio Compliance 2.0 for iOS connection

Hardware features

Two analogue mic/line inputs on XLR/TRS balanced combo connectors

High-quality Ultra-HDDA (High Definition Discrete Architecture) microphone pre-amps with ultra-low noise (EIN: –128 dBu)

Wide input gain range of 56 dB, ideal for dynamic microphones

Switchable 48-Volt phantom power on XLR inputs

TRS inputs 1/2 can each be switched to instrument-level for direct recording of guitar or bass

Two line outputs (balanced TRS)

Direct monitor option for low-latency monitoring

Monitor mix control for adjusting the level balance between signals from external devices and signals from the computer

Headphones output delivering 18 mW per channel

Independent level controls for line and phones outputs

MIDI input/output

USB bus-powered for mobile recording

Standalone operation as a simple preamplifier for practice sessions and more

Rugged aluminum body

Angled industrial design for ease-of-use on a desktop

Software features

In-house developed driver for Windows devices ensures stable operation with low latency

The buffer size for Windows can be selected up from 4 samples to facilitate a recording environment with ultra-low latency

Each input can be switched on/off individually

Input monitor mode can be selected between stereo and mono

You can select which signals are output at the line outputs

A loopback function allows two audio channels from the computer to be merged with the input signals and send this mix to the streaming or communication software

Input and computer signals can each be selected between stereo and mono

A slider lets you adjust the broadcast level

Switchable auto power save mode to reduce battery consumption on the laptop/tablet computer in mobile use

Automatic update function available for software, driver and firmware updates (you can install new updates with the press of a button)

Bundled with Cubase LE and Cubasis LE3 and Antares Auto-Tune Unlimited (free 3-month subscription)

Compatible with major DAW software (Pro Tools, Live, Cubase, Studio One, GarageBand)
