Enova 5-pins XLR hann chassisplugg, sort IP67 Outdoor

ENOVA 5 POL HAN XLR CHASSIS STIK, SORT IP67 OUTDOOR

ENOVA er en ny sveitsisk produsent av kontakter og kabler av høy kvalitet. ENOVA tilbyr et sortiment av de mest etterspurte kontakter og kabler i Live- og AV-industrien og vil løpende utvide sitt sortiment.
ENOVA streber etter å tilby Live- og AV-industrien et fullverdig alternativ.

Brand:ENOVA
Series:XLIP-Serie
Version (Plug / Chassis):Chassis version
Connector type:XLR, XLR male 5 pol
Number of contacts:5
Gender (M / F):Male plug
Connector housing color:Black
Wiring mode:Solder contact
Installation diameter in mm:Ø 24.00 mm
Installation fixing height x width in mm:24.00 mm x 19.00 mm
Number of mounting holes:2
Mounting hole diameter mm:3.5 mm
Material connector housing:PA
Material contact:H59-1
Waterproof component:TPR
Working temperature minimum:-30°
Working temperature maximum:+80°
IP protection class according to EN60529 2000:IP67
Classification flammability of plastics:UL94HB
ROHS according to EN62321-1:Ja
Country of origin:China
Operating voltage (VAC.RMS):Insulation resistance:> 10 GOhm
Contact resistance:<3 mOhm
Applications:DJ, Keyboard player, Lighting technician, Singer, Sound engineer
Märkte:Event Production, LED interior / exterior lighting, Industrie, Medical technology, Mechanical engineering, Gerätebau, Anlagenbau, Multimedia Installation, Digital Signage, Cable Assembly, Beleuchtung, LED Aussen Display, Broadcast, Recording studio
